Read Moreitem no. :
CS-CZ4-001Material : Zirconia, Silica
Purity Available : ZrO2=58-65% , SiO2=30-37%
Shape : Ball
1. High Density: Zirconium silicate beads have a high density, which makes them ideal for grinding and milling applications.
2. Superior Wear Resistance: These beads exhibit excellent wear resistance, ensuring a longer lifespan and consistent performance, even when used in abrasive environments or with hard materials.
3. Chemical inertness: They have chemical inertness and do not react with most chemical substances or solvents.
4. Low Contamination: Zirconium silicate beads have low levels of impurities, ensuring minimal contamination of the product being processed.
5. High Crushing Strength: These beads possess high crushing strength, which helps maintain their shape and integrity during grinding or milling processes, even under high pressure or stress conditions.
6. Heat Resistance: They can withstand high temperatures without significant degradation, making them suitable for applications that involve elevated temperatures, such as in ceramics and refractories.
1. Zirconium silicate beads are primarily composed of zirconium silicate, which is a crystalline mineral formed from zirconium, silicon, and oxygen. This composition gives the beads exceptional properties that make them ideal for milling and grinding applications.
2. They are renowned for their unique characteristics and play a crucial role in various industries.
3. These beads are used as grinding balls or grinding media in various industrial processes involving particle size reduction, grinding, and dispersion.
Zirconium Silicate Beads | |
Item No. | Diameter(mm) |
CS-CZ4-001 | 0.4-0.6 |
CS-CZ6-002 | 0.6-0.8 |
CS-CZ8-003 | 0.8-1.0 |
CS-CZ10-004 | 1.0-1.2 |
CS-CZ12-005 | 1.2-1.4 |
CS-CZ14-006 | 1.4-1.6 |
CS-CZ16-007 | 1.6-1.8 |
CS-CZ18-008 | 1.8-2.0 |
CS-CZ20-009 | 2.0-2.2 |
CS-CZ22-010 | 2.2-2.5 |
CS-CZ25-011 | 2.5-2.8 |
CS-CZ28-012 | 2.8-3.2 |
CS-NZB3-013 | 3.5-4.0 |
CS-NZB4-014 | 4.0-5.0 |
CS-NZB5-015 | 5.0-6.0 |
CS-NZB6-016 | 6.0-7.0 |
CS-NZB7-017 | 7.0-9.0 |
CS-NZB9-018 | 9.0-10.0 |
OEM/ODM is acceptable. Your goods will be produced exactly according to your drawings or inquiry.
1. Paints and Coatings: Zirconium silicate beads are used in the formulation of paints and coatings to disperse pigments and achieve a consistent color and finish.
2. Ceramics: In the ceramics industry, they are used for grinding, milling, and dispersing ceramic materials.
3. Minerals Processing: They are employed in the mining and minerals processing industry for grinding and milling purposes.
4. Pharmaceuticals: They can be used in pharmaceutical formulations, particularly for drug manufacturing processes.
5. Ink and Printing: They are used in the ink and printing industry to disperse pigments and dyes in printing inks.
6. Electronics Manufacturing: These beads are used in electronics manufacturing processes, such as circuit board production, for grinding and milling electronic materials to specific particle sizes, ensuring optimal performance of electronic components.
7. Wastewater Treatment: In wastewater treatment, these beads may be used for grinding and milling processes involved in the production of treatment chemicals or the preparation of flocculants.
Specific Gravity | Moh's Hardness | Vickers Hardness | Crushing Strength | Loss per ton |
>4.0kg/dm3 | <7.0 | >900kg/mm2 | >1000N(2mm) | <0.05kg/T |
Q1. How to choose the appropriate zirconium silicate beads for my application?
Consider factors like the material to be processed, desired particle size, required purity, and equipment specifications to select the appropriate bead size and type.
Q2. Can zirconium silicate beads be reused?
Yes, zirconium silicate beads can be reused after cleaning and quality inspection.
Q3. What is the typical lifespan of zirconium silicate beads?
The lifespan can vary depending on usage conditions and material processed, but these beads are known for their durability and extended operational life.
Q4. Can zirconium silicate beads be recycled or disposed of safely?
Yes, they can be recycled after use.
1. Wear Protective Gear: Before handling the grinding balls, wear appropriate personal protective equipment such as gloves and safety goggles to prevent skin contact and eye irritation.
2. Remove Residue: If there are visible residues on the grinding balls, gently remove them using a soft brush or cloth. Avoid using abrasive materials that could scratch the surface.
3. Rinse with Solvent: Immerse the grinding balls in a suitable solvent or cleaning solution.Allow the grinding balls to soak for a few minutes to loosen any adhered particles.
4. Agitate Gently: Gently agitate the solution to help dislodge any particles or contaminants from the surface of the grinding balls.
5. Ultrasonic Cleaning: For thorough cleaning, you can use an ultrasonic cleaner. Place the grinding balls and solvent in the ultrasonic bath and run it for a set duration, following the manufacturer's instructions. Ultrasonic cleaning can help remove stubborn residues.
6. Rinse with Distilled Water: After cleaning in the solvent, rinse the grinding balls with distilled water to remove any residual solvent or cleaning solution.
7. Dry Thoroughly: Place the cleaned grinding balls on a clean surface or in a container lined with a lint-free cloth to air dry.
1. Cracks or Damage: Inspect the beads for any cracks, chips, or visible damage. Damaged beads may need to be discarded.
2. Dimensional Inspection:Measurement the dimensions of the glass milling media balls to check for accuracy.Ensure that the dimensions are within the specified tolerances.
3. Use of Magnification: For a more detailed inspection, you can use a magnifying glass or microscope to examine individual beads closely. This can help detect microscopic cracks or defects that may not be visible to the naked eye.
