item no. :
CS-A-05Color :
White90% 92% 95% 99.5% 99.7% 99%
Material : Alumina ceramic
Shape : OEM
Size : OEM
Alumina ceramic thermocouple insulator tubes advantages:
1. Alumina ceramic thermocouple insulator tubes are highly resistant to corrosion, making them ideal for extreme environments.
2. Lightweight and durable, allowing for easy installation and maintenance.
3. They provide superior thermal insulation, allowing them to withstand higher temperatures than other materials.
4. Their non flammable and non-toxic properties make them safe for various applications.
5. High temperature resistance,1600℃ in long use,1800℃ in short use (Al2O3≥99%).
Alumina ceramic thermocouple insulator tubes descriptions:
1. Alumina ceramic thermocouple insulator tubes are made from high-grade alumina ceramic, providing superior thermal insulation for thermocouples.
2. Their superior hardness and chemical resistance make them ideal for a variety of industrial applications.
3. These tubes are designed to insulate thermocouple probes, minimizing heat loss and improving accuracy of temperature readings.
4. These reliable tubes offer superior insulation and protection against high temperatures and corrosive materials.
Alumina ceramic thermocouple insulator tubes size details:
OEM: All sizes can be customized and can be made into various complex shapes with high dimensional accuracy. Please clearly provide the height, bottom diameter, top diameter, wall thickness and any special requirements. To speed up the quotation, please provide drawings.
The data detail of our alumina material:
The data detail of our alumina material | ||||
Item | Unit Symbol | 95% Alumina Ceramic | 99% Alumina Ceramic | 99.7% Alumina Ceramic |
Maximum Using Temperature | ℃ | 1450 | 1600 | 1650 |
Water Absorption | % | 0 | 0 | 0 |
Hardness | Gpa | ≥85 | ≥89 | ≥89 |
Flexural Strength | MPa (psi x 103) | 336 | 550 | 550 |
Compressive Strength | MPa (psi x 103) | 2000 | 2500 | 2500 |
Fracture Toughness | Mpa | 4~5 | 5.6 | 6 |
Thermal Conductivity | W/m °K | 18-25 | 30 | 30.4 |
Thermal Shock Resistance | °C | 220 | 180-220 | 180-220 |
Dielectricity Constant | 9.4 | 9.8 | 9.8 |
Alumina ceramic thermocouple insulator tubes applications:
1. Alumina ceramic thermocouple insulator tubes are used as insulation for high temperature applications in power plants, petrochemical and oil refineries. They provide an effective barrier against heat transfer and help to protect sensitive components and instrumentation from extreme temperatures.
2. They are well-suited for use in scientific laboratories and medical research facilities. They can be used to protect and accurately measure the temperature of sensitive laboratory equipment and medical instruments.
3. For aerospace applications, they are used to protect and accurately measure the temperature of aircraft engines and other sensitive components.
4. For food processing facilities to accurately measure the temperature of food products. These tubes are an ideal choice for applications where the temperature needs to be measured accurately and reliably.
5. They can be used to measure the temperature of automotive internal combustion engines and other sensitive components.
FAQ
Q1. What information should we supply to get a quote?
Please offer the specification of ceramic tube, such as shape, dimension, quantity, application etc.
Q2. Are alumina ceramic thermocouple insulator tube customizable?
Yes, alumina ceramic thermocouple insulator tube can be customized to meet specific application requirements. Depending on the application, they can be made in different shapes and sizes, as well as with different finishes, to suit the specific needs of the customer.
Q3. How long do alumina ceramic thermocouple insulator tubes last?
Alumina ceramic thermocouple insulator tube is designed to last for many years depending on the application and environmental conditions. For example, furnace insulation tubes can last for up to 10 years.
Q4. What is the lead time for the alumina ceramic thermocouple insulator tube?
The lead time for the alumina ceramic thermocouple insulator tube is dependent on the size and quantity required. Please contact us for more infor.
How to clean alumina tube:
1. Begin by vacuuming the outside of the tube to remove any debris or dust.
2. Use a mild detergent and scrub the tube with a soft cloth or brush.
3. Use a mild abrasive or a toothbrush to scrub the inside of the tube.
4. Rinse the inside and outside of the tube with warm water and a soft cloth.
5. Use a clean, lint-free cloth to dry it.
Quality testing standards:
1. Visual inspection of the tube for any signs of damage or irregularities.
2. Measurement of the length, diameter, and thickness of the tube to check for accuracy.
3. Checking for any leaks or pinhole defects in the tube.
4. Testing for proper adhesion of the end cap to the tube.
5. Verification of the material and chemical composition of the tube.
Packing way:
Production Process:
Why Choose us?
1. We supply personalized and customized services to contact your personal needs.
2. We are experienced professionals with a good record of success.
3. We provide superior client service and promptly respond to all inquiries.
4. We provide militant prices and strive to ensure that your funds receive the best value.
5. We use the latest technologies and tools to ensure that your project is completed to the highest standards.
