High-Quality Glass Cuvettes for Optical Lab Measurements & Analysis

Categories
Hot Products

Glass cuvette
High-Quality Glass Cuvettes for Optical Lab Measurements & Analysis High-Quality Glass Cuvettes for Optical Lab Measurements & Analysis High-Quality Glass Cuvettes for Optical Lab Measurements & Analysis High-Quality Glass Cuvettes for Optical Lab Measurements & Analysis High-Quality Glass Cuvettes for Optical Lab Measurements & Analysis

High-Quality Glass Cuvettes for Optical Lab Measurements & Analysis

The glass cuvette, a common lab optical component, is widely used for optical measurement & substance analysis.

  • item no. :

    CS-BSM-1001

  • Material : Quartz glass

contact now catalogue
  • description

Properties of Glass Cuvettes


  1. Excellent Light Transmission: Crafted from premium quartz and optical glass, it guarantees bubble-free, streak-free clarity. With a transmittance over 80% at 340nm, it ensures accurate, reliable optical measurements.

  2. Corrosion Resistance: Sealed using low-melting-point glass technology, it withstands 6mol/L sodium hydroxide, 6mol/L hydrochloric acid, anhydrous ethanol, carbon tetrachloride, and benzene for 24 hours without leakage, ideal for harsh lab environments.

  3. Robust Mechanical Strength: Designed with high mechanical strength and resilience to temperature changes, its firmly bonded parts can endure several atmospheres of pressure, ensuring smooth experiments and a long lifespan.




Applications of Glass Cuvettes


  1. Spectral Analysis Tool: Ideal for spectroscopic instruments and sample observation, it's a crucial tool for detecting and analyzing substance composition, making it a must-have in scientific research and analysis.

  2. Chemical Analysis Essential: It supports qualitative identification and quantitative analysis by measuring sample reflectance or transmittance using different wavelengths of light, enhancing the accuracy of chemical analysis results.

  3. Biomedical Imaging: In biomedical imaging technology, our cuvette provides precise and reliable measurements, aiding scientific research and medical fields in achieving accurate results.

  4. Environmental Monitoring: Widely used in water and air quality monitoring, it pairs seamlessly with UV-visible spectrophotometers to help assess pollution levels and water quality, contributing to environmental protection efforts.


Size Chart of Glass Cuvettes

Please provide drawing and parameter requirements for customization.



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1001 4 PCS Standard cell with lid and leve bottom(2mm) 700ul 2mm 12.5x4.5x45mm 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1002 4 PCS Standard cell with lid and leve bottom(1mm) 350ul 1mm 12.5x3.5x45 mm 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1002-1 0.2mm short range quartz glass cuvette 70ul 0.2mm 12.5x3.5x45 mm / JGS1



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1002-2 0.5mm short range quartz glass cuvette 170ul 0.5mm 12.5x3.5x45 mm / JGS1



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1002-3 2mm short range quartz glass cuvette 700ul 2mm 12.5x3.5x45 mm / JGS1



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1002-4 3mm short range quartz glass cuvette 1050ul 3mm 12.5x3.5x45 mm / JGS1



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1002-5 5mm short range quartz glass cuvette 1750ul 5mm 12.5x3.5x45 mm / JGS1



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1003 6ml Glass Sample cell cuvette （path length 10mm） Customization 6ml 10mm 15x16.5x75mm 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1004 10pcs standard glass cuvette (no lid) and leve bottom with 10mm path length 3.5ml 10mm 12.5x12.5x45mm 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1005 glass cuvettes 14.5ml 10mm 50x14x50mm 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1005-1 glass cuvettes 14ml 10mm 12.5*42.5*45mm / optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1006 4 PCS glass cuvettes cells with lid and round bottom(10mm)/Matching with spectrophotometer without glue 3.5ml 10mm 12.5x12.5x45mm 350nm-2000nm German optical glass


Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1007 Glass micro cuvette /350ul-1.75ml/ two-way light 0.35-1.75ml 10mm 12.5x12.5x45mm 350nm-2000nm glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1008 Glass square cylinder threaded hole with cap/Glass reaction cell/four-way light/cap with threaded hole 24ml 20/40mm 44x22x31mm 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1009 Glass fluorescent cuvette cell  9ml 8/28mm 30x45x10mm 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1010 1.4ml Glass Sample cell （path length 1mm/25mm） 1.4ml 1mm/25mm 55x31x11mm / /


Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1011 4 PCS Standard cell with lid and leve bottom(100mm) 35ml 100mm 125x102.5x45mm 350nm-2000nm German optical glass


Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1012 4 PCS Standard cell with lid and leve bottom(50mm) 17.5ml 50mm 12.5x52.5x45mm 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1013 4 PCS Standard cell with lid and leve bottom(40mm) 14ml 40mm 12.5x42.5x45 mm 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1014 4 PCS Standard cell with lid and leve bottom(3mm) 1.05ml 3mm 12.5x5.5x45 mm 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1015 40mm Glass cuvette cell （14ml） 14ml 40mm 12.5x42.5x45mm 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1015-1 glass cuvettes 14ml 10mm 12.5x42.5x45mm 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1016 Square glass container 5ml 10mm 12.5x12.5x62mm 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1016-1 Square glass container 7ml 10mm 12.5x12.5x82mm 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1017 4PCS Standard cell with lid and leve bottom(30mm) 10.5ml 30mm 12.5x32.5x45 mm 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1018 4PCS Standard cell with lid and leve bottom(20mm) 7ml 20mm 12.5x22.5x45 mm 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1018-1 glass cuvette standard 35ml 100mm 12.5*102.5*45mm 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1019 Glass micro cuvette /350ul-1.75ml/Semi-micro micro diagonal slit sample cell 350ul-1.75ml 10mm 12.5*12.5*45mm 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1020 4 PCS Standard cell with lid and leve bottom(5mm) 1.75ml 5mm 12.5x7.5x45mm 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1021 581 Glass cuvette cell 4ml 5mm 65x17.5x9mm 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1022 Residual chlorine cuvette 20ml 25mm 29x16x70mm 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1022-1 Residual chlorine cuvette 10ml 12mm 23*16*54mm 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1023 1 PCS Standard cell with lid and leve bottom(5mm) 1.75ml 5mm 12.5x7.5x45mm 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1024 quartz glass cuvette 2.5ml 10mm 12.5*12.5*45mm / optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1025 glass cuvettes customization 1.4ml 1mm/25mm 53*31*11mm 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1026 glass cuvettes with positioning block 67ml 21mm/46mm / 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1027 glass cuvettes customization 7ml-51ml 5mm-51mm / 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1027-1 glass cuvettes customization 72ul 3mm 5*5*10mm 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1027-2 glass cuvettes customization 1ml 1.5mm 30*3.5*30mm 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1027-3 glass cuvettes customization 9ml 8mm/28mm 30*10*45mm 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1027-4 glass cuvettes customization 100ml 37mm/57mm 60*40*50mm 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1027-5 glass cuvettes customization 200ml 66mm 70*70*48mm,
hole φ 8mm 		350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1027-6 glass cuvettes customization / / / 350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1028 photoelectric cuvettes 3.5ml-70ml 5mm-100mm 24*9*40mm
24*14*40mm
24*24*40mm
34*24*40mm
54*24*40mm
104*24*40mm 		350nm-2000nm German optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1029 Roverpen cuvette / 133.4mm 137.4*20*40m / optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1030 Roverpen cuvette 30ml 50.8mm 54.8*20*40mm / optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1031 Roverpen cuvette 3.8ml 6.4mm 10.4*20*40mm / optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1032 Roverpen cuvette 15ml 25.4mm 29.4*20*40mm / optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1033 Roverpen cuvette 7ml 12.7mm 16.7*20*40mm / optical glass



Item no. Description Capacity Path Length LxWxH Wavelength Range Material
CS-BSM-1034 Roverpen cuvette 6ml 10mm 14*20*40mm / optical glass



Tags : Measurement cuvette Analytical cuvette Glass cuvette Lab cuvette Optical cuvette
