laboratory analysis ceramic consumables
Manufacturer of Industrial Precision Ceramics
Ceramic Crucible Leco 528-018. Manufacturer of carbon sulfur crucible & cs crucible for LECO CS230. Eltra 90148/90149/90150/90152 Horiba 905.200.380.001 Bruker: JW-N009250423 Alpha AR3818 SerCon: SC0893 LECO528-018/002-301/002-302 Elementar 905.200.380.001 AN. Used for Carbon sulfur Analyzer Elemental Analysis.
Read More
Alumina tubes both sides open are commonly used in various industrial and laboratory applications. They are ideal for use in processes such as heating, cooling, and drying, and can offer superior thermal and electrical insulation.
Read More
Alumina Ceramic Substrate Sheet is an ideal choice for applications requiring high performance, reliability, and durability. It is available in various sizes and thicknesses to suit different applications.
Read More
Achieve unparalleled levels of purity with our Bone Ash Cupels. Engineered to remove impurities and unwanted elements, these cupels enable you to extract the true essence of your precious metals.
Read More
Alumina pipes advantage:high heat resistance,good cold-resistance heat-resistance,resistance to acid and alkali corrosion. Long service life. OEM is accpected.
Read More
Alumina crucible and boat are wildly used in laboratory and industrial analysis as well as metal and nonmetal material sample melting.Available in various sizes and shapes.
Read More
Circle alumina ceramic rods have a higher strength to weight ratio than other ceramics, and can be used to manufacture lighter and stronger parts.Available in a variety of sizes and shapes.
Read More
952018.906 100μl Platinum/Pt Crucibles(Sample Pans) for TA Instruments TA Q500/Q50/TGA 2950/2050. Manufacturer for TA crucibles and DSC sample pans. TA Instruments tga analyser good alternative sample cups.
Read More
Zirconia ceramic are used in shaft, plunger, sealing structure, auto-mobile industry, oil drilling equipment, insulation parts in electrical equipment, ceramic knife, ceramic hair clipper spare parts, with high density, bending strength and breaking tenacity. We can supply the products according to customer's drawings, samples and performance requi1
Read More
1. Do different size of Platinum/PT Crucibles as you need.2. Send us design drawing or specification of Platinum/PT Crucibles . Manufacturer of Platinum/PT Crucibles .CS CERMAIC CO.,LTD
Read More
item no. :
CS-SY-GG1001Material : Quartz glass
High-Temperature Resistance: Quartz crucibles offer exceptional high-temperature resistance, with a maximum use temperature of up to 1600°C. This makes them ideal for high-temperature applications in the semiconductor and photovoltaic industries.
Excellent Thermal Shock Resistance: With superior thermal shock resistance, quartz crucibles can maintain stability under extreme temperature fluctuations. This ensures reliable performance and longevity in high-temperature environments.
High Purity & Arc Fused Method: Arc fused quartz crucibles are produced using a high-purity method that ensures they have low impurity levels. This makes them suitable for sensitive applications in the semiconductor and photovoltaic industries.
Corrosion Resistance & Insulation Performance: Quartz crucibles are highly resistant to corrosion and offer excellent insulation performance. This makes them suitable for a wide range of chemical processes and ensures safe operation in electrical applications.
Arc fused quartz crucibles are primarily used in the monocrystalline silicon growth process in the semiconductor and photovoltaic industries. They are designed for continuous crystal pulling under high-temperature conditions, ensuring high-quality production and efficiency.
Please provide drawing and parameter requirements for customization.
| Quartz Crucible | |||||||||
| Item no. |
OD (mm) |
H (mm) |
T (mm) |
R (mm) |
r (mm) |
Gap (mm) |
Si2O's Purity (%) |
||
| W1 | W2 | W3 | |||||||
| CS-SY-GG1001 | 355.6 ± 2.0 | Customization Available | 8.5 ± 2.0 | 10.5 ± 2.0 | 8.5 ± 2.0 | 381 | 89 | ≤5 | 99.99 |
| CS-SY-GG1002 | 406.5 ± 2.5 | 9.0 ± 2.0 | 11.0 ± 2.0 | 9.0 ± 2.0 | 406 | 76 | |||
| CS-SY-GG1003 | 457.0 ± 2.5 | 9.5 ± 2.0 | 11.5 ± 2.0 | 9.5 ± 2.0 | 500 | 120 | |||
| CS-SY-GG1004 | 505.0 ± 3.0 | 10.0 ± 2.0 | 11.0 ± 2.0 | 10.0 ± 2.0 | 508 | 90 | |||
| CS-SY-GG1005 | 555.0 ± 3.0 | 11.0 ± 2.0 | 12.0 ± 2.0 | 11.0 ± 2.0 | 558 | 130 | |||
| CS-SY-GG1006 | 607.0 ± 3.0 | 12.0 ± 2.0 | 13.0 ± 2.0 | 12.0 ± 2.0 | 609 | 120 | |||
| CS-SY-GG1007 | 632± 3.0 | 11± 2.0 | 11± 2.0 | 14± 2.0 | 635 | 120 | |||
| CS-SY-GG1008 | 655.0 ± 3.0 | 12.0 ± 2.5 | 14.5 ± 2.5 | 12.0 ± 2.5 | 669 | 120 | |||
| CS-SY-GG1009 | 710.0 ± 3.0 | 12.0 ± 2.5 | 16.0 ± 2.5 | 12.0 ± 2.5 | 710 | 120 | |||
| CS-SY-GG1010 | 758± 3.0 | 13.5± 2.0 | 13.5± 2.0 | 19.0± 3.0 | 760 | 120 | |||
| CS-SY-GG1011 | 810.0 ± 3.0 | 14.0 ± 2.5 | 23.0 ± 2.5 | 14.0 ± 2.5 | 810 | 160 | |||
| CS-SY-GG1012 | 912.0 ± 3.0 | 18.0 ± 2.5 | 26.0 ± 2.5 | 18.0 ± 2.5 | 910 | 180 | |||
| CS-SY-GG1013 | 1016.0 ± 3.0 | 20.0 ± 3.0 | 30.0 ± 3.0 | 20.0 ± 3.0 | 1016 | 186 | |||
99.99% Transparent Cylindrical Quartz Crucible Silica Glass Crucibles
Cylindrical quartz glass crucibles are specialized containers made specifically for high temperature applications, which provides exceptional resistance to corrosion, and chemical attack.Available in various sizes.
99.99% Transparent Conical Quartz Crucible with Lid SiO2 Glass Crucibles
Conical quartz glass crucibles are made from high purity quartz glass and are conically shaped,this design allows for efficient heat transfer and uniform distribution of heat throughout the crucible,available in various sizes.
99.99% Transparent Square Quartz Glass Crucibles Silica Crucibles
Square quartz glass crucibles have a perfectly square design,offers more space for samples and ensures uniform heating,making them an ideal choice for precision experiments and studies.Available in various sizes.
99.98% 99.99% Transparent Quartz Boats SiO2 Glass boats
Quartz boats are inert to most chemicals, including acids, alkalis, and organic solvents. They are easy to clean, sterilize, and reuse.Available in various sizes and shapes, from miniature crucibles to larger containers.
Opaque Quartz Crucible
Opaque Quartz Crucibles are laboratory consumables, which used for holding and heating materials in laboratories.
High-Temp Quartz Lab Dish Evaporation & Crystallization Tool
The high-temp, corrosion-resistant quartz evaporating dish adapts to harsh environments, ensuring reliable evaporation, concentration, and crystallization of solutions.
Transparent 99.98% Quartz Glass Beaker
99.98% quartz glass beaker has high economic benefits,and is an essential piece of equipment for any laboratory or research facility requiring precise measurements and accurate results.Available in various sizes.
Diameter 130mm Porcelain Desiccator Plate with Small Holes
1.Diameter of Porcelain Desiccator Plate 130mm 2.Center hole diameter 33mm. Large hole diameter 30mm 3.Small hole diameter 27mm
