Sub-Micro Quartz Cuvette Ultra-Small Glass for Precision Optical Analysis

Categories
Hot Products

Sub-Micro Quartz Cuvette
Sub-Micro Quartz Cuvette Ultra-Small Glass for Precision Optical Analysis Sub-Micro Quartz Cuvette Ultra-Small Glass for Precision Optical Analysis Sub-Micro Quartz Cuvette Ultra-Small Glass for Precision Optical Analysis Sub-Micro Quartz Cuvette Ultra-Small Glass for Precision Optical Analysis Sub-Micro Quartz Cuvette Ultra-Small Glass for Precision Optical Analysis

Sub-Micro Quartz Cuvette Ultra-Small Glass for Precision Optical Analysis

The Sub-Micro Quartz Cuvette is an ultra-small, high-perf glass cuvette for precision optical analysis, ideal for spectral analysis & chemical reaction monitoring.

  • item no. :

    CS-BSM-4001

  • Material : Quartz glass

contact now catalogue
  • description

Properties of Sub-Micro Quartz Cuvettes


  • High Precision Measurement: This cuvette offers extremely high measurement accuracy, making it ideal for the precise analysis of small samples. Its design ensures data accuracy, which is crucial for reliable scientific research and lab work.
  • High-Quality Quartz Material: Made from high-quality quartz, this cuvette boasts excellent light transmission and chemical stability. It can withstand the erosion of various chemical reagents, ensuring durability and extending its service life.
  • Wide Range of Applications: Suitable for a variety of laboratory equipment, including fluorescence photometers and spectrophotometers, this cuvette is compatible with most standard-size sample holders. Its ultra-small capacity and high performance make it a versatile tool for spectral analysis, chemical reaction monitoring, and other precision optical measurements.



Applications of Sub-Micro Quartz Cuvettes


  • Environmental Monitoring Applications: This cuvette is ideal for water quality analysis and air pollutant detection in environmental monitoring. Its ability to provide accurate data support helps evaluate environmental quality and support sustainable development efforts. Whether you're working in academia, industry, or government, the Sub-Micro Quartz Cuvette is a versatile and reliable tool for your precision optical measurement and analysis needs.
  • Microfluorescence Analysis: Perfect for fluorescence analysis of small samples, this cuvette accurately measures the fluorescence intensity of low-concentration samples, providing reliable data for scientific research. Its high sensitivity and precision make it an essential tool for microfluorescence analysis in various fields.
  • Spectral Measurement Capabilities: Suitable for a wide range of spectral measurements, including UV-VIS and infrared spectroscopy, this cuvette helps researchers analyze the chemical composition and structure of samples. Its high-quality quartz material ensures excellent light transmission, making it ideal for spectral measurements that require high accuracy and reliability.
  • Drug Research and Development: In the field of drug development, the Sub-Micro Quartz Cuvette is used for quantitative analysis of drug molecules, supporting the process of new drug discovery and optimization. Its high precision and accuracy make it a valuable tool for researchers working on drug candidates and formulations.


Size Chart of Sub-Micro Quartz Cuvettes

Please provide drawing and parameter requirements for customization.




Item no. Description Capacity Path Length LxWxH Wavelength Range
CS-BSM-4001 1pcs Micro quartz fluorescence cuvette with lid(350ul) 350ul 10mm 12.5x12.5x45mm 200nm-2500nm




Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4002 1pcs Micro quartz fluorescence cuvette with lid(700ul) 700ul 10mm 12.5x12.5x45mm 200nm-2500nm 100℃




Item no. Description Capacity Path Length LxWxH Wavelength Range
CS-BSM-4002-1 Micro quartz fluorescence cuvette (300ul) 300ul 4mm/10mm 12.5x12.5x45mm 200nm-2500nm



Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4003 2pcs 700ul Micro cell with black walls and lid/ 2mm Inside Width 0.7ml 10mm 12.5x12.5x45mm 200nm-2500nm（Quartz）
350nm-2000nm(Glass）
Slit 2mm 		100℃



Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4003-1 Micro cell with black walls 350ul 10mm 12.5x12.5x45mm 200nm-2500nm（Quartz）
350nm-2000nm(Glass）
Slit 1mm 		100℃




Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4003-2 Micro cell with black walls 1400ul 10mm 12.5x12.5x45mm 200nm-2500nm（Quartz）
350nm-2000nm(Glass）
Slit 4mm 		100℃



Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4003-3 Micro cell with black walls 1750ul 10mm 12.5x12.5x45mm 200nm-2500nm（Quartz）
350nm-2000nm(Glass）
Slit 5mm 		100℃



Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4003-4 Micro cell with black walls 1050ul 10mm 12.5x12.5x45mm 200nm-2500nm（Quartz）
350nm-2000nm(Glass）
Slit 4mm 		100℃




Item no. Description Capacity Path Length LxWxH Wavelength Range
CS-BSM-4004 Quartz cuvette cell with screw cap(10mm)/Two way light/700ul/Slit 2mm 700ul 10mm 12.5x12.5x50mm 200nm-2500nm
Slit 2mm




Item no. Description Capacity Path Length LxWxH Wavelength Range
CS-BSM-4005 Quartz cuvette cell with screw cap(10mm)/350ul/400ul/600ul/Slit 1/2/3mm 350ul/400ul/600ul 10mm 12.5x12.5x45mm 200nm-2500nm
Slit 1/2/3mm




Item no. Description Capacity Path Length LxWxH Wavelength Range
CS-BSM-4006 Quartz trace fluorescence cell with stopper(10mm)/1.05ml/ Slit 3mm 1.05ml 10mm 12.5x12.5x45 mm 200nm-2500nm
Slit 3mm




Item no. Description Capacity Path Length LxWxH Wavelength Range
CS-BSM-4007 1pc Quartz micro cuvette (10mm)700ul 700ul 10mm 12.5x12.5x45mm 200nm-2500nm




Item no. Description Capacity Path Length LxWxH Wavelength Range
CS-BSM-4007-1 Quartz micro cuvette fluorescence cell 700ul 10mm 12.5x12.5x45mm 200nm-2500nm




Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4008 20ul Quartz Fluorescent Micro Cuvette Cell (path length 10mm) 20ul 10mm 12.5x12.5x45mm 200nm-2500nm 100℃




Item no. Description Capacity Path Length LxWxH Wavelength Range
CS-BSM-4009 Micro quartz fluorescence cuvette with lid(700ul) 700ul 10mm 12.5x12.5x45 mm 200nm-2500nm




Item no. Description Capacity Path Length LxWxH Wavelength Range
CS-BSM-4010 Sub-Micro fluorescence quartz cell with black walls and lid(45ul) 45ul 3x3mm 12.5x12.5x45mm 200nm-2500nm



Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4010-1 Micro quartz cuvette 50ul 10mm 12.5x12.5x45mm 200nm-2500nm 100℃




Item no. Description Capacity Path Length LxWxH Wavelength Range
CS-BSM-4011 800ul Customized Quartz micro cuvette cell 800ul 10mm 12.5x12.5x35mm 200nm-2500nm




Item no. Description Capacity Path Length LxWxH Wavelength Range
CS-BSM-4012 Quartz trace cell with stopper(10mm)/1.4ml/ Slit 4mm 1400ul 10mm 12.5x12.5x45 mm 200nm-2500nm




Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4013 Micro quartz Screw Sealed Cuvette with lid (350ul-1750ul) 350ul/700ul/1050ul/1400ul/1750ul 10mm 12.5x12.5x53mm 200nm-2500nm 1200℃




Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4014 Micro quartz fluorescence cuvette with lid(560ul) 560ul 4mm 12.5x12.5x45mm 200nm-2500nm 600℃




Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4015 200ul Quartz micro fluorescence cuvette cell Central Height 15mm 200ul 4/10mm 12.5x12.5x45mm 200nm-2500nm 600℃




Item no. Description Capacity Path Length LxWxH Wavelength Range
CS-BSM-4015-1 100ul Quartz micro fluorescence cuvette cell Central Height 15mm 100ul 2mm/10mm 12.5x12.5x45mm 200nm-2500nm




Item no. Description Capacity Path Length LxWxH Wavelength Range
CS-BSM-4016 200ul Quartz Micro Fluorescence Cuvette Cell Central Height 8.5mm 200ul 4/10mm 12.5x12.5x45mm 200nm-2500nm




Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4017 Sub-Micro fluorescence quartz cell with black walls and lid(50ul) for lab 50ul 10mm 12.5x12.5x45mm 200nm-2500nm 100℃



Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4018 200ul Quartz micro fluorescence cuvette cell Central Height15mm 200ul 10mm 12.5x12.5x45mm 200nm-2500nm 100℃



Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4019 Sub-Micro quartz fluorescence cuvette with lid(100ul) 100ul 10mm 12.5x12.5x45mm 200nm-2500nm 100℃




Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4020 Micro quartz fluorescence cuvette no lid 140ul 140ul 4mm/1mm 12.5x12.5x45mm 200nm-2500nm 100℃



Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4021 20ul Quartz micro cuvette cell （path length 10mm） 20ul-200ul 10mm 12.5x12.5x45mm 200nm-2500nm 100℃




Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4022 Sub-Micro quartz cell with black walls and lid(50ul) 50ul 10mm 12.5x12.5x45mm 200nm-2500nm 100℃




Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4023 Sub-Micro quartz cell with black walls and lid(100ul) 100ul 10mm 12.5x12.5x45mm 200nm-2500nm 100℃




Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4024 Sub-Micro quartz cell with black walls and lid(300ul) 300ul 10mm 12.5x12.5x45mm 200nm-2500nm 100℃




Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4025 Sub-Micro quartz cell with black walls and lid(200ul) 200ul 10mm 12.5x12.5x45mm 200nm-2500nm 100℃




Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4026 1pcs Micro Quartz Fluorescence Cuvette With Lid(1400ul) 1400ul 10mm 12.5x12.5x45mm 200nm-2500nm 100℃




Item no. Description Capacity Path Length LxWxH Wavelength Range
CS-BSM-4026-1 Micro Quartz Fluorescence Cuvette 1.4ml 4mm/10mm 12.5x12.5x45mm 200nm-2500nm




Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4027 Micro cell with frosted walls and lid(350ul) 350ul 10mm 12.5x12.5x45mm 200nm-2500nm 600℃




Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4028 Sub-Micro quartz cell with black walls and lid(50ul) for lab 50ul 10mm 12.5x12.5x45mm 200nm-2500nm 100℃




Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4029 1pcs Micro quartz fluorescence cuvette with lid(1050ul) 1050ul 10mm 12.5x12.5x45mm 200nm-2500nm 600℃




Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4030 Micro cell with frosted walls and lid(1.4ml) 1.4ml 10mm 12.5x12.5x45mm 200nm-2500nm 600℃




Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4031 Micro cell with frosted walls and lid(1.05ml) 1.05ml 10mm 12.5x12.5x45mm 200nm-2500nm 600℃




Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4031-1 Micro cell with frosted walls and lid(1.75ml) 1.75ml 10mm 12.5x12.5x45mm 200nm-2500nm 600℃




Item no. Description Capacity Path Length LxWxH Wavelength Range
CS-BSM-4032 Quartz cell with stopper(10mm)/350ul/slit 1mm/fluorescence 350ul 10mm 12.5x12.5x45 mm /




Item no. Description Capacity Path Length LxWxH Wavelength Range
CS-BSM-4033 Sub-Micro fluorescence quartz cell with black walls and lid(50ul) 50ul 10mm 12.5x12.5x45 mm /




Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4033-1 Micro quartz cell with black walls 2100ul 30mm 12.5*32.5*45mm 200nm-2500nm 100℃




Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4034 Micro cell with frosted walls and lid(700ul) 700ul 10mm 12.5x12.5x45mm 200nm-2500nm 600℃




Item no. Description Capacity Path Length LxWxH Wavelength Range Temp.
CS-BSM-4035 1pcs Micro quartz fluorescence cuvette with lid(1750ul) 1750ul 10mm 12.5x12.5x45mm 200nm-2500nm 100℃




Item no. Description Capacity Path Length LxWxH Wavelength Range
CS-BSM-4036 Micro quartz fluorescence cuvette(4 polished sides) 0.35ml-1.75ml 10mm 12.5x12.5x45mm 200nm-2500nm




Item no. Description Capacity Path Length LxWxH Wavelength Range
CS-BSM-4037 Micro quartz fluorescence cuvette(2 polished sides) 0.35ml-1.75ml 10mm 12.5x12.5x45mm 200nm-2500nm




Item no. Description Capacity Path Length LxWxH Wavelength Range
CS-BSM-4038 Micro quartz fluorescence cuvette 1.75ml 5mm/10mm 12.5x12.5x75mm 200nm-2500nm




Item no. Description Capacity Path Length LxWxH Wavelength Range
CS-BSM-4039 Micro quartz fluorescence cuvette 500ul 5mm/10mm 12.5*7.5*45mm 200nm-2500nm




Item no. Description Capacity Path Length LxWxH Wavelength Range
CS-BSM-4040 Micro quartz fluorescence cuvette
customized 		106ul 10mm 12.5x12.5x8mm 200nm-2500nm




Item no. Description Capacity Path Length LxWxH Wavelength Range
CS-BSM-4041 Micro quartz fluorescence cuvette 2 polished sides 50ul/100ul 50ul/100ul 10mm 12.5*12.5*45
slit 2mm 		200nm-2500nm


Tags : Sub-Micro Quartz Cuvette Ultra-Small Glass Cuvette Precision Optical Cuvette Spectral Analysis Cuvette Chemical Reaction Monitoring Cuvette
