item no. :
CS-ZTA-CL0001Material : ZTA
Abrasion Resistance for Extended Durability:
The ZTA ceramic lining plate, renowned for its high hardness and exceptional wear resistance, effectively shields pipelines and equipment from abrasive wear, ensuring a longer service life. This durability is a top priority in industries seeking reliable, long-lasting solutions.
Lightweight Design for Easy Installation:
Boasting a low specific gravity and lightweight construction, the ZTA ceramic lining plate offers ease of installation, significantly reducing equipment load and simplifying maintenance processes. Its manageable weight makes it an ideal choice for a variety of applications.
Impact Resistance for Enhanced Safety:
With superior tenacity and impact resistance, the ZTA ceramic lining plate significantly minimizes the impact of materials on equipment, safeguarding against potential damage and enhancing overall system safety.
Smooth Surface for Efficient Material Flow:
The smooth surface of the ZTA ceramic lining plate minimizes material transportation resistance, preventing accumulation and ensuring smooth, efficient operation. This feature is crucial in industries requiring seamless material handling.
The Zirconia Toughened Alumina Ceramic Lining Plate is perfect for coal transportation systems, material handling systems, pulverizing systems, ash removal, and dust extraction systems in sectors such as thermal power, steel, metallurgy, coal mining, mining, chemicals, and cement. Its ability to safeguard pipelines from abrasion and extend service life makes it a vital component in these demanding environments.
| Zirconia Toughened Alumina Lining Plate | ||||
| Item No. |
Length (mm) |
Width (mm) |
Thickness (mm) |
Purity (Al2O3+ZrO2) |
| CS-ZTA-CL0001 | 10 | 10 | 1.5 | 74%+23.5% |
| CS-ZTA-CL0002 | 10 | 10 | 3 | 74%+23.5% |
| CS-ZTA-CL0003 | 10 | 10 | 4 | 74%+23.5% |
| CS-ZTA-CL0004 | 10 | 10 | 5 | 74%+23.5% |
| CS-ZTA-CL0005 | 10 | 10 | 8 | 74%+23.5% |
| CS-ZTA-CL0006 | 10 | 10 | 10 | 74%+23.5% |
| CS-ZTA-CL0007 | 12 | 12 | 3 | 74%+23.5% |
| CS-ZTA-CL0008 | 12 | 12 | 4 | 74%+23.5% |
| CS-ZTA-CL0009 | 12 | 12 | 5 | 74%+23.5% |
| CS-ZTA-CL0010 | 12 | 12 | 6 | 74%+23.5% |
| CS-ZTA-CL0011 | 12 | 12 | 8 | 74%+23.5% |
| CS-ZTA-CL0012 | 12 | 12 | 10 | 74%+23.5% |
| CS-ZTA-CL0013 | 17.5 | 17.5 | 3 | 74%+23.5% |
| CS-ZTA-CL0014 | 17.5 | 17.5 | 4 | 74%+23.5% |
| CS-ZTA-CL0015 | 17.5 | 17.5 | 5 | 74%+23.5% |
| CS-ZTA-CL0016 | 17.5 | 17.5 | 6 | 74%+23.5% |
| CS-ZTA-CL0017 | 17.5 | 17.5 | 8 | 74%+23.5% |
| CS-ZTA-CL0018 | 17.5 | 17.5 | 10 | 74%+23.5% |
| CS-ZTA-CL0019 | 20 | 20 | 3 | 74%+23.5% |
| CS-ZTA-CL0020 | 20 | 20 | 4 | 74%+23.5% |
| CS-ZTA-CL0021 | 20 | 20 | 5 | 74%+23.5% |
| CS-ZTA-CL0022 | 20 | 20 | 6 | 74%+23.5% |
| CS-ZTA-CL0023 | 20 | 20 | 8 | 74%+23.5% |
| CS-ZTA-CL0024 | 20 | 20 | 10 | 74%+23.5% |
| CS-ZTA-CL0025 | 25 | 25 | 3 | 74%+23.5% |
| CS-ZTA-CL0026 | 25 | 25 | 5 | 74%+23.5% |
| CS-ZTA-CL0027 | 25 | 25 | 8 | 74%+23.5% |
| CS-ZTA-CL0028 | 25 | 25 | 10 | 74%+23.5% |
| CS-ZTA-CL0029 | 25 | 25 | 12 | 74%+23.5% |
| CS-ZTA-CL0030 | 25 | 25 | 15 | 74%+23.5% |
| CS-ZTA-CL0031 | 30 | 37 | 4 | 74%+23.5% |
| CS-ZTA-CL0032 | 45 | 25 | 5 | 74%+23.5% |
| CS-ZTA-CL0033 | 70 | 62 | 10 | 74%+23.5% |
| CS-ZTA-CL0034 | 100 | 75 | 8 | 74%+23.5% |
| CS-ZTA-CL0035 | 200 | 175 | 4 | 74%+23.5% |
| CS-ZTA-CL0036 | 205 | 130 | 4.5 | 74%+23.5% |
| CS-ZTA-CL0037 | 25-800 | 25-800 | 3-40 | 74%+23.5% |
High Hardness ZTA Ceramic Substrate Wear Resistant ZTA Substrate
The ZTA ceramic substrate, made of alumina & zirconia, is sintered at high temp, offering hardness, wear resistance, & toughness ideal for demanding apps.
Wear & Corrosion Resistant ZTA Ceramic Lining Brick Extends Equipment Life
ZTA lining bricks, alumina-zirconia blend, high-temp resistant, wear-resistant, extend ball mill & equipment life.
ZTA Ceramic Grinding Balls Ultra-Fine Grinding Media for High Hardness Abrasives
ZTA grinding balls feature high mechanical strength, fracture toughness, wear resistance, heat & corrosion resistance, ideal for ultra-fine grinding of high hardness abrasives.
Chemical Resistant Zirconia Toughened Alumina (ZTA) Ceramic Lining Board
ZTA Lining Board offers high temp resistance, acid/alkali resistance, chemical stability, hardness, wear resistance, and toughness, crucial in mechanical, high-temp fire, chemical, and metallurgy industries.
High Temp ZTA Ceramic Tube Resistant to Acids & Alkalis Zirconia Toughened Alumina Pipe
ZTA Tube, resistant to high temp & acids/alkalis, combines hardness & wear resistance with toughness, ideal for refractory, chemical and metallurgy industries.
High-Temp Zirconia Toughened Alumina ZTA Ceramic Rod & Bar for Industrial Use
ZTA Rod offers high temp, acid/alkali resistance, chemical stability, hardness, wear resistance, and toughness, crucial in mech eng, high-temp, chemical, electrical, metallurgy industries.
ZTA Ceramic Ring Wear-Proof for Mechanical Fixation
ZTA Ceramic Ring, crafted from alumina & zirconia, offers high-temp, corrosion resistance, wear-resistance, and toughness, ideal for mechanical fixation, sealing, and isolation.
3D Porous SiC Foam Filter 1500°C Resistance Filters Slag & Impurities in Molten Steel/Iron
The SiC foam filter, with a 3D porous structure, offers high temp resistance up to 1500°C, and good adsorption, filtering slag & impurities in molten steel/iron for uniform casting structure and smoother surfaces.
