Zirconia ceramic bar
ZrO2 Bar Zirconia Ceramic Strip Ceramic Bar ZrO2 Bar Zirconia Ceramic Strip Ceramic Bar

ZrO2 Bar Zirconia Ceramic Strip Ceramic Bar

Crafted from zirconia powder and stabilizers, our ZrO2 zirconia ceramic strips and bars undergo molding and sintering for exceptional quality.
  • item no. :

    CS-YHG-T1001
  • Material : ZrO2

  • description

Properties of Zirconia Ceramic Bar




  1. Robust Durability: High hardness, wear resistance, flexural strength, and impact resilience.
  2. Corrosion Protection: Resists acids, alkalis, and salts, ensuring long-term performance.
  3. Heat Resistance: Excellent thermal shock resistance and stable under high temperatures.
  4. Electrical Insulation: Low dielectric constant and loss, making them ideal for electrical devices.



Applications of Zirconia Bar

Widely used in machinery processing, petrochemicals, electrical engineering, and semiconductors, zirconia ceramic bars are customized to your needs, ensuring precision and surpassing expectations.




Size Chart for Zirconia Ceramic Bar

Please provide drawings and parametric specifications for customization.



Machining Tolerance: 0.001mm


Zirconia Ceramic Bar
Item No. Length
(mm)
Width
(mm)
Height
(mm)
CS-YHG-T1001 25 5 1.5
CS-YHG-T1002 63.5 7.7 1.5
CS-YHG-T1003 30 10 2
CS-YHG-T1004 191 10.5 3
CS-YHG-T1005 85 12 6
CS-YHG-T1006 204 12.8 3
CS-YHG-T1007 67 14.5 2.5
CS-YHG-T1008 75 15 3
CS-YHG-T1009 180 20 6
CS-YHG-T1010 225 25 6
CS-YHG-T1011 200 50 5
CS-YHG-T1012 10-600mm 1-50mm 1-20mm
