Zirconia ceramic has a series of good properties, such as high strength, good fracture toughness, high density, good abrasion resistance, high hardness and so on.
item no. :
CS-YHG-BY001Color :
WhitePort :
Any ports of Chinalead date :
5-7 daysMaterial : Zirconia ceramic
Purity : 95%
Shape : Rod
1. High Strength: Zirconia ceramic rods offer high strength and toughness, making them suitable for use in a wide range of applications.
2. Corrosion Resistance: Zirconia ceramic rods are highly resistant to corrosion and are able to withstand exposure to extreme temperatures and chemicals.
3. Wear Resistance: Zirconia ceramic rods possess excellent wear resistance, making them suitable for use in applications that require frequent abrasion.
4. Low Thermal Expansion: Zirconia ceramic rods have a low thermal expansion rate, making them ideal for use in areas where thermal shock is a concern.
5. Chemical Stability: Zirconia ceramic rods are highly stable in the presence of acid and alkali solutions, making them suitable for use in a variety of chemical and industrial applications.
6. Electrical Insulation: Zirconia ceramic rods offer good electrical insulation properties, making them suitable for use in electrical components and devices.
1. Used for high temperature furnaces, electrical insulators, and other thermal insulation materials.
2. Used in medical and dental implants, as well as in prosthetics.
3. Used in cutting tools, abrasives, and grinding media in machining, drilling, and grinding.
4. Used in wear-resistant parts in the automotive and aerospace industries.
5. Used in advanced fuel cells and other energy storage devices.
6. Used in pumps, valves, and other applications where corrosion resistance is important.
7. Used as a catalyst in chemical reactions.
8. Used in fuel injectors, spark plugs, and other automotive components.
Property |
Value |
Color |
White |
Density |
6.0g/cm3 |
Flexural strength |
1150MPa |
Compressive strength |
2500MPa |
Max use temperature |
1500℃ |
Thermal conductivity |
2.5W/(m·K) |
Thermal expansion coefficient |
(8~10)×10-6℃ |
Specific heat |
500J/(Kg·K) |
Dielectric strength |
5KV/mm |
Dielectric constant |
12Er |
Item | Outside Dia / mm | Length / mm | Purity |
CS-YHG-BY001 | 1 | Customize | 95% |
CS-YHG-BY002 | 2 | Customize | 95% |
CS-YHG-BY003 | 3 | Customize | 95% |
CS-YHG-BY004 | 4 | Customize | 95% |
CS-YHG-BY005 | 5 | Customize | 95% |
CS-YHG-BY006 | 6 | Customize | 95% |
CS-YHG-BY007 | 7 | Customize | 95% |
CS-YHG-BY008 | 8 | Customize | 95% |
CS-YHG-BY009 | 9 | Customize | 95% |
CS-YHG-BY010 | 10 | Customize | 95% |
CS-YHG-BY011 | 11-20 | Customize | 95% |
CS-YHG-BY012 | 21-30 | Customize | 95% |
1.specifying a zirconia ceramic rod are size, shape, material, surface finish, and machining.
2.The material used will depend on the application and desired performance.
3.Common zirconia ceramic materials used include Zirconium Oxide (ZrO2), Yttria Stabilized Zirconia (YSZ), and Silicon Carbide (SiC).
4.The surface finish can also vary depending on your application and can range from smooth polished to blasted or etched finishes. In terms of machining, the rods can be cut to size, drilled, or tapped to fit your needs.
1. Visual inspection: Check for any surface defects such as cracks, chips, or scratches.
2. Density test: Measure the density of the material to ensure it meets the desired specifications.
3. Hardness test: Measure the hardness of the material using a hardness testing device.
4. Strength test: Measure the tensile strength of the material to ensure it meets the desired specifications.
5. Chemical analysis: Analyze the material to determine its chemical composition and identify any impurities.
6. Thermal shock test: Subject the material to extreme temperatures and measure its resistance to thermal shock.
7. Corrosion resistance test: Measure the material’s resistance to various corrosive agents.
8. Impact test: Drop a weight onto the material and measure its resistance to impact.
9. Flexural strength test: Measure the flexural strength of the material to ensure it meets the desired specifications. 10. Thermal expansion test: Measure the thermal expansion of the material to ensure it meets the desired specifications.
As a professional industrial ceramic supplier, we have a series of advantages that guarantee our market share in the international trade market.
1.Reliable quality control, complete specifications, support customization of non-standard products
1.Q: What is a zirconia ceramic rod?
A: zirconia ceramic rod is a type of ceramic material made from zirconium oxide. It has a high strength-to-weight ratio, excellent electrical insulation properties, and excellent resistance to wear and corrosion. Zirconia ceramic rods are often used in applications such as electrical insulation, thrust bearings, and wear-resistant parts.
2.Q: What are the benefits of using zirconia ceramic rods?
A: Zirconia ceramic rods are lightweight, strong, and corrosion-resistant. They also have excellent thermal and electrical insulation properties, making them ideal for use in high temperature and electrical applications. Additionally, zirconia ceramic rods are non-toxic and biocompatible, making them a safe choice for medical implants and other applications.
