Crucibles for Netzsch TGA Sample Carrier (HTP40000A58.000-00) of the STA 449 F1/F3/F5 Jupiter, STA 449 F3 Nevio
|
Material (Purity/%) |
Temperature Range |
Consisting of |
Dimension/ (ø x Height)/ Volume |
Remarks | Order Number |
| Al2O3 (99.7) | Max. 1700°C | Slip-on plate, flat | ø 10 mm | GB343550 | |
| Al2O3 (99.7) | Max. 1700°C | Slip-on plate | ø 17 mm | GB445240 | |
| Al2O3 (99.7) | Max. 1700°C | Crucible | 0.9 ml | GB445215 | |
| Al2O3 (99.7) | Max. 1700°C | Lid | For GB445215 | GB445216 | |
| Al2O3 (99.7) | Max. 1700°C | Crucible | 0.9 ml | Highly sintered | NGB820039 |
| Al2O3 (99.7) | Max. 1700°C | Lid | For NGB820039 | NGB820040 | |
| Al2O3 (99.7) | Max. 1700°C | Crucible | 3.4 ml | GB445213 | |
| Al2O3 (99.7) | Max. 1700°C | Lid |
Lid without hole, for GB445213 |
GB445214 | |
| Al2O3 (99.7) | Max. 1700°C | Crucible | 3.4 ml | Highly sintered | NGB820041 |
| Al2O3 (99.7) | Max. 1700°C | Lid |
Lid without hole, for NGB820041 |
NGB820042 | |
| Al2O3 (99.7) | Max. 1700°C | Crucible | 5.0 ml | NGB809163 | |
| Al2O3 (99.7) | Max. 1700°C | Lid |
Lid without hole, for NGB809163 |
NGB814785 | |
| Al2O3 (99.7) | Max. 1700°C | Crucible | 5.0 ml | Highly sintered | NGB820037 |
| Al2O3 (99.7) | Max. 1700°C | Lid |
Lid without hole, for NGB820037 |
NGB820038 | |
| Al2O3 (99.7) | Max. 1700°C | Crucible |
For sample dimension: ø 15 mm; hight 25 mm |
NGB811934 | |
| Al2O3 (99.7) | Max. 1700°C | Crucible |
ø 18 mm; øinner14.5 mm; total height 14.5 mm; filling height 3 mm; volume 0.53 ml |
For glove box applications |
NGB811194 |
CSCERAMIC provide all of the above crucibles .Email info@csceramic.com
