item no. :
CS-A-13Color :
White90% 92% 95% 99.5% 99.7% 99%
Material : Alumina ceramic
1. Alumina ceramic milling jars with covers are extremely durable, making them ideal for grinding heavy and abrasive materials.
2. Heat resistant, ideal for high-temperature grinding operations.
3. Highly resistant to corrosion, which means they do not degrade over time.
4. Extremely low porosity, which means they are less likely to absorb contaminants during the grinding process.
5. Non sticky, which makes them easy to clean and maintain.
1. Alumina ceramic milling jar with cover is an essential tool for any serious laboratory or workshop.
2. It is made of high-grade alumina ceramic, which ensures long-lasting durability and performance.
3. Its generous capacity allows you to mill larger amounts of materials at once.
4. This jar is great for grinding, crushing, and mixing samples for a variety of applications.
Item | Model & Specification | Capacity | Outer diameter * Height(mm) |
Appro.net weight
(in kgs)
|
Alumina Ceramic Grinding Jars with Cover | CS | 30-40L | 400*600 | |
XL size | 18-18.5 | 300*400 | 18 | |
L size | 15-16 | 300*330 | 14~15 | |
One-size | 10-14 | 270*320 | 11 | |
Two-size | 5-6.5 | 220*260 | 9 | |
Three-size | 3-5 | 180*250 | 6 | |
Four-size | 1.5 | 150*180 | ||
Five-size | 1 | 130*170 | 5 |
OEM/ODM is acceptable. Your goods will be produced exactly according to your drawings or inquiry
Item No. |
Outer Diameter
(mm)
|
Height
(mm)
|
Capacity
(L)
|
CS-AM-012 | 300 | 350 | 10-15 |
CS-AM-013 | 240 | 240 | 5L |
CS-AM-014 | 190 | 190 |
2L |
1. Alumina ceramic milling jar with cover can be used for pulverizing minerals and other materials in a laboratory setting. The ceramic material provides an inert environment for grinding, allowing for precision and accuracy.
2. Ideal for use in food processing, pharmaceuticals and personal care products, where contamination must be controlled. This jar can be used to efficiently grind and mix ingredients without introducing any unwanted particles into the mix.
3. It is often used in the pharmaceutical industry for grinding active ingredients, excipients and other materials into a fine powder. The ceramic material ensures the purity of the product.
4. Widely used in high temperature furnaces. This jar is an ideal choice for accurately measuring and mixing materials in a high-temperature environment.
5. Ideal for use in industrial processes such as milling, grinding, and blending of powders and other materials. The ceramic material provides an inert environment that is resistant to abrasion and corrosion.
Material | 85%Al203 | 90%Al203 | 95%Al203 | 99%Al203 |
Al203 | 0.85 | 0.9 | 0.93 | 0.993 |
Fe2O3 | ≤1.0 | ≤0.5 | ≤0.5 | ≤0.3 |
Desnsity:g/cm3 | 3.4 | 3.5 | 3.6 | 3.85 |
Vickers Hardness | ≥8.6 | ≥8.8 | 9 | 9 |
Water Absorption:% | ≤0.2 | ≤0.1 | ≤0.085 | ≤0.01 |
Refractoriness:℃ | 1580℃ | 1600℃ | 1650℃ | 1800℃ |
Flexural Strength:Mpa | 180 | 200 | 240 | 280 |
Wear Rate(at room temperatureerosion 100 grinding)% | ≤3 | ≤2.5 | ≤1 | ≤0.5 |
Q1. What information should we supply to get a quote?
Please offer the specification of alumina ceramic milling jar with cover, such as shape, dimension, quantity, application etc.
Q2: What types of materials can be milled in an alumina ceramic milling jar?
Alumina ceramic milling jars are suitable for grinding and milling a wide variety of materials, including chemicals, pigments, and other substances.
Q3: What size of alumina ceramic milling jar do I need?
The size of the alumina ceramic milling jar you need will depend on the size and type of milling media you are using
Q4: How often should I replace my alumina ceramic milling jar?
It depends on the frequency of use and the type of material being milled. Generally, alumina ceramic milling jars should be replaced after 1-2 years of use.
1. Wash the jar and lid separately with water to remove any debris.
2. Use a soft cloth and mild detergent to scrub the inside of the jar and lid.
3. Use a soft brush and mild detergent to scrub the outside of the jar and lid
4. Rinse the jar and lid with water, and then dry with a soft cloth.
5. Ensure that the grinding tank is dry when used again.
1. Visually inspect the jar for any signs of wear and tear such as cracks, chips, or any other visible damage.
2. Make sure the lid is properly sealed and there are no gaps that could allow for particles to escape.
3. Check the threads of the lid and the jar body for any signs of stripping or damage.
4. Ensure the lid fits tightly and securely on the jar body.
5. Inspect the seals around the lid and the jar body for any signs of damage or wear.
6. Check the interior of the jar for any signs of contamination such as dust, dirt, or other materials.
7. Check the exterior of the jar for any signs of corrosion or other damage.
1. We supply personalized and customized services to contact your personal needs.
2. We are experienced professionals with a good record of success.
3. We provide superior client service and promptly respond to all inquiries.
4. We provide militant prices and strive to ensure that your funds receive the best value.
5. We use the latest technologies and tools to ensure that your project is completed to the highest standards.
Alumina ceramic pots mill grinding jars have extremely high abrasion resistance, long service life, negligible contamination factor, available in a variety of sizes, shapes and colors.
Alumina grinding balls are high-density and ultra-high fired ceramic balls used in high-intensity stirred mills for fine and ultra-fine grinding. Available in various sizes.
Inert Alumina Ceramic Ball as a catalyst in the reactor to cover support material and tower packing.Available in various sizes.
Alumina ceramic milling jar has a wide mouth and a flat bottom, allowing for easy stirring and efficient grinding,available in a variety of sizes.
Desiccant Catalyst Carrier Activated Alumina Balls can be used as a catalyst as well as a adsorbent.Available in various sizes.
Alumina ceramic mill jars with monolithic construction,big round arc angle.The mouth of pot can be sealed and opened easily, hard and durable. Bad phenomena such as gap,leak,dead space ect can not occur in use.
Alumina ceramic mill jars are cylindrical,heavy-duty containers designed to hold and process materials such as chemicals, minerals, and pharmaceuticals, available in a variety of sizes.
Alumina ceramic milling jar have monolithic construction,big round arc angle. The mouth of pot can be sealed and opened easily, hard and durable.Bad phenomena such as gap,leak,dead space ect can not occur in use.
