TA 960070.901/ 961060.901 alumina sample cups
90μl Premium alumina sample cups 960070.901/ 961060.901 for TA Instruments SDT Q600/SDT 2960 (Sample pans) 90μl Premium alumina sample cups 960070.901/ 961060.901 for TA Instruments SDT Q600/SDT 2960 (Sample pans) 90μl Premium alumina sample cups 960070.901/ 961060.901 for TA Instruments SDT Q600/SDT 2960 (Sample pans) 90μl Premium alumina sample cups 960070.901/ 961060.901 for TA Instruments SDT Q600/SDT 2960 (Sample pans) 90μl Premium alumina sample cups 960070.901/ 961060.901 for TA Instruments SDT Q600/SDT 2960 (Sample pans) 90μl Premium alumina sample cups 960070.901/ 961060.901 for TA Instruments SDT Q600/SDT 2960 (Sample pans)

90μl Premium alumina sample cups 960070.901/ 961060.901 for TA Instruments SDT Q600/SDT 2960 (Sample pans)

TA 960070.901/ 961060.901 Alumina crucibles sample pans for TA Instruments SDT Q600/SDT 2960. Manufacturer for TA crucibles and DSC sample pans. TA Instruments good alternative sample pans.

  • item no. :

    CS-TA-022
  • Suitable for : TA Instruments

  • Material : ceramic

  • Part NO : 960070.901/ 961060.901

  • description

90μl Premium alumina sample cups 960070.901/ 961060.901 for TA Instruments SDT Q600/SDT 2960 (Sample pans)


Item info :


Type Sample pan /crucible
Suitable for TA SDT Q600/SDT 2960
Part NO

TA 960070.901

TA 961060.901(disposable)

Volume μL 90 μL
Lid

Without(if need lids, Alumina Lids P/N 960239.901 is for use with Alumina Sample Cups P/N 960070.901)

Material Alumina Ceramic
Temperature range Room temperature to 1600℃
QTY/PKG 20PCS/BOX ;  100PCS/BOX (Both available)
Brand CS CERAMIC
Original MADE IN CHINA



Usage:

TA alumina crucible(sample pans) is made of high-purity aluminum powder, with application of advanced sintering process, to produce small sized crucible that specified for thermal analysis, with four features below to fulfill various kinds of thermal analysis test.



Alumina sample cups feature:

1.High thermal conductivity: heat transfer between sample and crucible is very fast, so temperature difference between them is very small and temperature distribution is homogeneous.

2.Stable structure: high-purity powder and precise controlled sintering process, to make dense and homogeneous micro crystal phase, so to ensure stable structure and no physical or chemical reaction during the process of usage.

3.High temperature stability: with wide working temperature range, available up to 1600℃

4.High repeated utilization ratio: wash by water or 10% hydrochloric acid and dry the crucible after using, it can be used again and without disturbance to analysis test.



Alumina Sample Pans 960070.901/ 961060.901 for Thermal Analysis(click to review the video)



Guide to TGA Pan Selection - TA sample pan, Platinum pan, Aluminum pan, Ceramic Alumina Pan




Size details:

OEM: All sizes can be customized and can be made into various complex shapes with high dimensional accuracy. Please clearly provide the height, bottom diameter, top diameter, and any special requirements. To speed up the quotation, please provide drawings.
